Simpson Minilab PVF-C - Specifications, Dimensions and Weights (Approximate)

Short Description & Specifications 3
man-CH-PVF-C-V17-2 Minilab 13
3.4 Specifications, Dimensions and Weights (Approximate)
Specifications
Minilab
Length
830 mm (32.6 in)
Width
400 mm (15.7 in)
Height
250 mm (9.8 in)
Weight
56 kg (123.4 lbs.)
Power
230 V - 50 Hz
Air Compressed
Min. 5 bar
Max. 10 bar
Test Selection
Accessory
Standard Range
Max. Range
Force
-
3000 N
5000 N
Compression Strength
-
153 N/cm
2
255 N/cm
2
Splitting Strength
-
120 N/cm
2
200 N/cm
2
Twin-Transverse Shear
Strength
PQS/M
76.4 N/cm
2
127 N/cm
2
Core Transverse Strength
PBV/M
6006 N/cm
2
10009 N/cm
2
Core Tensile Strength
PZV/M
598 N/cm
2
996 N/cm
2
High Compression
Strength
PHD/M
917 N/cm
2
1528 N/cm
2
Component
PVF-C
PLC (Programmable Logic Control)
Siemens CPU 313C
CP 340 RS232C
Power supply unit PSU100S AC
120/230V; 24V DC/2.5A
Display
Siemens Simatic HMI KP400
Comfort
Path Measurement
Transmetra path sensor
Path sensor amplifier Phönix
Load Measurement
Force absorber HBM 5kN
Force measurement amplifier
HBM AE101
Pneumatic Measurement
Festo pneumatic cylinder
Festo pneumatic valve
