Safety 2
man-CH-PVF-C-V17-2 Minilab 5
2.1.2 Safety Symbol Labels
NO CHANGE OR PART SUBSTITUTIONS
(STC #998-4725)
This label is located on the left side of the panel enclosure above
the main switch.
No changes or part substitutions shall be made on this equipment
without consulting Simpson Technologies. Changes may compromise
safety features, resulting in a hazardous situation.
PINCH POINTS
(STC #998-4727)
This label is located on the Piston of the pneumatic cylinder.
With the service doors open, body parts may be crushed or cut
between the Piston and Minilab Base Plate from both intentional and
unintentional movement of the piston. Follow Lockout and Tagout
procedures before servicing and always ensure Protection Doors are
closed before testing.
