4 Unpacking and Installation
20 Minilab man-CH-PVF-C-V17-2
A pressure regulator/filter and fittings required to connect the Minilab
to the regulator/filter have been included with the equipment package
and will need to be attached to the machine as shown in Figure 8.2.
Supplying a pneumatic hose from the air supply to Minilab fittings is
the responsibility of the customer.
The compressed air should be free of dirt, debris
and condensate. Debris and condensate will cause
damage to the equipment.
4.5 Connecting Power and Set-Up
1. Verify the voltage on the specification plate located on the
back of the Minilab. Connect the power cable supplied with
the equipment into the power plug receptacle located on the
back of the machine (Figure 8.2, Item 6).
Some environments may require an electrical plug that is not supplied
with the power cord in order to properly conform to the specific
electrical outlet. These special electrical plugs will need to be
purchased separately by the customer
2. Verify the proper voltage of the electrical outlet before
plugging the power cord into the outlet. Connect power cord
to the AC electrical outlet that is free of
disturbances/fluctuation and is properly grounded.
It is highly recommended that a voltage
stabilizer/filter (line conditioner) is installed
between the electrical outlet and the inlet of the
Minilab. This device will help to ensure the proper
performance of the equipment.
3. Connect the Minilab to the factory pneumatic supply line,
connection located on the rear of device.
4. Turn on the air supply. Using the supplied air
regulator/filter/lubricator adjust the air pressure to 5 bar (70-75
PSI). Refer to the manufacturer's manual for the
regulator/filter for instructions on regulating air pressure.
