4 Unpacking and Installation
18 Minilab man-CH-PVF-C-V17-2
3. Once removed from the crate, proceed by taking off any protective
wrap and packaging from the testing equipment and included
accessories.
4. The packaging remains the property of the customer and may be
used for returning the apparatus if repair is ever required.
4.2 Components
The following items are included with the Minilab:
• Operating Instructions Manual
• Connecting Cable – PC 9 Pole
• Power Cable 230V
• Specimen Tube 120mm
• Ramming Pedestal Type F
• Sand Chute Collection Base
• Transverse Strength Attachment (Model PBV/M)
• Twin-Transverse Shear Strength Attachment (Model PQS/M)
The following are available as accessories:
• Screening Device for Preparation Sample (Model PES)
• Tensile Strength Device (Model PZV/M)
• High Pressure Measuring Device (Model PHD/M)
• 50 mm Round Calibration Insert
• Test Spring with Load-Path Diagram
If any of the above components are missing (excluding accessories),
contact your local Simpson Technologies office. See Figures 8.1 – 8.3
for apparatus layout and components.
Do not store the device in the open and
unprotected from atmospheric conditions. If this
instruction is not followed, claims under guarantee
will no longer be considered.
