Simpson Minilab PVF-C - High Pressure Measuring Device (Model PHD;M)

3 Short Description & Specifications
16 Minilab man-CH-PVF-C-V17-2
3.5.5 High Pressure Measuring Device (Model PHD/M)
This accessory is mounted on the Minilab, Model PVF-C, and is used
to determine high-pressure compression strength of foundry sands.
With the PHD/M base plate mounted on the Minilab, a standard sand
specimen of 50 mm x 50 mm is placed on the Minilab pedestal and
placed below the squeeze pinch. The PHD/M roller is pressed down
by the minilab piston and results in a compression force with a force
factor of 6.
Specifications
Transverse Strength
Attachment
Length
ca. 245 mm (9.65 in.)
Width
ca. 120 mm (4.72 in.)
Height
ca. 168 mm (6.61 in.)
Weight
ca. 15.6 kg (34.4 lb.)
