Unpacking and Installation 4
man-CH-PVF-C-V17-2 Minilab 19
4.3 Installation
The installation of the apparatus is the responsibility of the client to
include procuring and preparing the material required for this purpose.
The Minilab should be placed on a stable, non-slippery surface, free of
vibrations. This surface should also have sufficient load-bearing
capacity to support the weight of the Minilab. It is also recommended
that the machine be placed in a level condition to yield more accurate
test results.
The Minilab would likely be operated by one person at a time. This
equipment is for use in a foundry sand laboratory. It is recommended
that the equipment be placed at an ergonomically efficient position,
with display at eye level, to facilitate the placement and measurement
of test specimens & equipment.
4.4 Electrical and Pneumatic Power Connection
Electrical requirements: 230 Volts, 50 Hz
Pneumatic requirements: compressed air, filtered and regulated
between 5 and 10 bar (72 psi and 145 psi).
This equipment includes a connecting plug and integrated fuse 230V
AC / 50 Hz. The connection to power supply is by means of this
supplied power cable.
Before connecting the equipment, an approved pneumatic
safety Lock-Out air valve must be installed in the supply air-
line. This item is not supplied with the equipment and is the
responsibility of the customer to provide and install.
Verify that the voltage marked on the serial number
nameplate is the same as the electrical outlet to be used for
the machine. The outlet must be properly grounded! Failure to
follow safety procedures could result in serious injury.
