Simpson Minilab PVF-C - Page 61

Apparatus Layout 8
man-CH-PVF-C-V17-2 Minilab 55
Item Symbol Description
1 Permeability Symbol
2 - Permeability Interface
3 Wet Tensile Strength Symbol
4 - Wet Tensile Strength Interface
5 Print Symbol
6
-
Printer (or PC) Connection
7 - Pressure Regulator
8 - Shut-off Ball Valve
9 - Power Connection Outlet
