AIS Class B Transceiver
16
2.8 SD card (Not supplied)
The SD card slot is situated on the reverse of the unit under a water
resistant cover, Fig. 2.5.
Note DO NOT insert or remove the SD card while the AI50 is powered up.
Locate and undo the two retaining screws, and carefully remove the cover
to reveal the SD card slot.
With the SD card contact side down, place under the shroud and slide fi rmly
into place, making sure the card is sitting squarely and not at an angle.
Replace the cover and screw back into place, making sure not to over
tighten the screws.
Note The use of high speed SD cards is not recommended. Use Class 1 SD
cards only.
Access Cover
Retaining Screws
Shroud
Fig. 2.5 - SD Card Access Cover
