CA34/44/54 Miscellaneous menu Chapter 7-13
7.7.1 Satellites in SDGPS system
The SDGPS system consist of eight orbiting geostationary satel-
lites and is designed to form a seamless global augmentation system
consisting of Waas (USA), EGNOS (Europe) and MSAS (Japan). If
all three parts would become operative at the same time, there would
be no performance problem. However, since WAAS is the only
system currently in normal operation, the WAAS correction signals
can have a negative effect on receivers operating in Europe and Far
East outside the intended WAAS coverage area. In these areas, we
recommend that the ‘SDGPS select mode’ is changed from ‘AUTO’
to ‘PASSIVE’.
Refer to Addendum no. 183-0002-000 (included in the package) for
up-to-date information on the current status of the SDGPS system.
Number Name System Area
120
AOR-E EGNOS - EU
Atlantic ocean region east
122
AOR-W WAAS - US
Atlantic ocean region west
124
ARTEMIS EGNOS - EU
126
INMARSAT EGNOS - EU
129
MTSAT-1 MSAS - JAPAN
131
IOR EGNOS - EU
Indian ocean region
134
POR WAAS - US
Pacific ocean region
137
MTSAT-2 MSAS - JAPAN
Tracking state
The letter indicating the tracking state will appear immediately after
the satellite number in the display.
Letter indication: - means that the receiver is:
S searching for satellite.
D trying to synchronize to data stream.
C code locked to signal.
P phase locked to signal.
