Chapter 8-16 CA34/44/54 Waypoint / route menu
8.9 Data transfer via DataCard or disc
Data transfer to and from external memory can be performed via
Simrad DataCard (CA34/44/54), or with a Simrad TL50 Turbo
Loader (CA44/54) via an ordinary 1.44Mb disc.
DataCards and TL50 Turbo Loader are optional equipment available
from your local Simrad dealer.
How to perform data transfers via TL50 (including data from Ship-
mate RS2500 Trackplotter) is described in the TL50 manual.
Use the Simrad DataCard or TL50 Turbo Loader to make backup
files of all the user data you have created plus the current setups
in the internal memory of the unit. Do it whenever you have added
important data, or when you wish to transfer routes and waypoints,
etc. to another compatible unit. The storage capacity of the Data-
Card/TL50 disc is divided into two databanks of each 450 Kb, mean-
ing that the entire internal memory can be stored in one databank.
External memory with data transfer via DataCard:
MENU
Call up the menu bar, and...
6,8
load the Data transfer window
Data transfer
1
DataCard upper drawer
3
DataCard lower drawer
7
NMEA connection - see section 8.10
MENU
Exit
1
Select the drawer where you have inserted the DataCard e.g. [1]:
DataCard upper drawer
1
DataCard status
3
Save on DataCard
9
Load from DataCard
MENU
Exit
