Simrad CA34 User Manual

Chapter 2-6 CA34/44/54 Fundamentals & initial start-up
2.4 Menu layout
1
RADAR
2
CHART
3
ECHO
1
Radar
1
Chart
1
50kHz
2
Dual Radar
2
Dual Chart
2
200kHz
3
Radar & Chart
3
Custom screen 1
3
Dual Frequency (44/54)
4
Custom screen
4
Custom screen 2
4
Custom screen 1
5
Custom screen 2
4
PILOT
5
MISC
6
WP/RTE
1
Highway
1
Wind
1
Waypoints
2
Position
2
Speed diagram
2
Routes
3
Dual Speed
3
Decca lanes
3
Route calculation
4
ETA & AVN
4
Loran C
4
Lines
5
Trim & Highway
5
Satellites
5
Tracks
6
Set & Drift
6
DGPS
6
Targets
7
Custom screen 1
7
SDGPS
7
MOB data
8
Custom screen 2
8
DSC info
8
Data transfer
9
Depth & Temp. diagram
7
SETUP
When selecting a sub-
menu in the SETUP
menu, the display will
always appear in a
pop-up window, so once
you have accepted the
changes or decided to
just exit the display, then
the display will disappear
from the screen.
RADAR
Radar setup
2
Interface setup
CHART
C-MAP cartridge
3
Palette setup
ECHO
Echosounder setup
4
Factory settings
PILOT
Pilot/Position setup
5
QuickGuide
1
Speed alarm, units &
language
