Chapter 9-6 CA34/44/54 Setup menu

C-MAP cartridges

UPPER

Name: EAST DENMARK AND WEST SWEDEN

Code: EN-C161.4

Date: 14/09/2002

LOWER

Name:

Code:

Date:

Exit Test

ENT

Press [ENT] to test the data on the C-MAP C-card



If a C-card is defect, it must be removed before you can exit the display.

Exit the window

In addition to the larger boundaries of the world chart there will be

separate boundary lines for the individual charts stored on the same

cartridge. However, the boundary lines for the C-MAP chart areas

can be turned off, so they will not be visible on the chart - refer to

section 4.5 Chart setup.

Other chart areas can quickly be reached by means of the zoom keys:

Zoom out until desired area becomes visible

Move cursor to approximate area, and...

Zoom in

The chart will automatically start to move when cursor reaches the

edge of the screen. When cursor is switched off [CLR], the chart will

return to ship’s position.

9.3 Echosounder setup

The Echosounder setup display mainly consist of general settings,

but also applies to a specific frequency where stated. The CAXX

features single and dual transceiver transmitting at 38 (44/54), 50

and 200 kHz.

Call up the menu bar, and...
