Chapter 5-2 CA34/44/54 Echo menu
5.1 Echo menu
3
ECHO
1
50kHz (or 38kHz CA44/54)
2
200kHz
3
Dual Frequency (CA44/54)
4
Custom screen 1
5
Custom screen 2
Low and high frequency echosounder display can be set up sepa-
rately. The low frequency display will show deep water bottom
contours, and the high frequency display will show the mid-water
section with trawl targets or bait fish in a higher resolution.
The Dual Frequency display (CA44/54) will provide both the 50kHz
and the 200kHz echo displays in one screen.
The two custom screens will present multiple window combina-
tions (section 5.2), where one of the main echo displays i.e. 50kHz or
200kHz will be fixed in the left half of the screen. Adjustments can
be made individually to both displays (section 5.7).
To access one of the displays via the menu e.g.:
MENU
Call up the menu bar, and...
3,2
press [3] and [2] to call up the Echo display for 200kHz in full
screen - see display example on next page.
5.2 Shortcut to the pages in the echo-series
The ECHO function is one of the main functions in the CAXX. Each
page under the [ECHO] key will include a window representing the
echo function. It is not possible to exchange main function displays
with a new display. Refer to section 2.1, 2.1.1 and 2.1.2 for further
information on the display and page system.
