Chapter 8-18 CA34/44/54 Waypoint / route menu
User data generated by other chartplotter models e.g. CE33/40/42/52,
CP33/40/42/52, CA40/42/52, CR40/42/52 can all be transferred to a
CA34/44/54 unit via the Data transfer system.
However, it is not immediately accessible to transfer data via Data-
Card from the new model CA34/44/54 to the older model CA42, etc.,
as this would require an update of the CA42.
- For more information, please contact an authorized Simrad dealer.
Load from DataCard: DATABANK-1
Data generated by: Simrad CA44
Used internal memory: 193393 bytes = 42%
Used DataCard memory: 2677 bytes = 1%
Used internal memory after operation: 191400 bytes = 42%
Date saved: 15-02-2003
Time saved: 19:43:00
Name:
Data type
Internal
Amount Bytes
DataCard
Amount Bytes
Internal
after
Amount Bytes
Action
Marks/waypoints:
Lines:
Routes:
Targets:
Tracks:
Setup:
9 244
0 0
1 168
0 0
8 190480
1 2501
11 256
2 168
4 408
1 100
0 0
1 1745
9 244
2 168
4 408
1 100
8 190480
0 0
NO
OVERWRITE
OVERWRITE
OVERWRITE
NO
NO
MENU
Exit Load selected data from DataCard
ENT
Use the cursor key to go to the ‘Ac t io n’ column to decide which
action you want taken for each mentioned category of data (toggle
with +/- keys) - see section 8.9.1.
If you choose to MERGE the data already stored in the Internal
memory with the data coming from the DataCard, the bottom line in
the window will ask you to press [ENT] to: Calculate databank after
merge.
ENT
Press [ENT] to activate ‘Load selected data from DataCard’
You will now receive a warning about which data in the internal
memory of the unit will be overwritten. Press [ENT] to accept.
After the data has been transferred, you will receive a status report.
