GOTO
Presentation Dep
PLOT
►
Display mode OVERLAY
Orientation NORTH UP
Rotation resolution 15°
Motion RELATIVE
Extended level range OFF
MENU
Exit Accept
ENT
∆
∆
General
Chapter 3-20 CA34/44/54 Radar menu
Color presets for the overlay display
Different color combinations of radar targets and chart or radar
background color are available:
PWR
Call up the Light and power pop-up window
1 - 9
Select a different number in the color Palette
ENT
Confirm the change
The color palettes from 1 to 4 are fixed, palette 9 is preset with multi
color radar targets, the rest (5-8) can be customized to suit individual
needs. See how in section 9.7.
Adjustment of overlay settings
The special chart used with the overlay is not used anywhere else in
the system and therefore has its own individual setup. A description of
the chart features can be found in section 4.5.2. To access the overlay
chart setup, the active window must contain a radar display, and then:
ENT
Call the Radar quick menu
ADJ
Open for change in the overlay chart setup
