C-MAP attributes Appendix C-3

Exit Chart info

 Use the same procedure to locate a Hospital, Coast Guard, Fuel Sta-

tion, Public Telephone, Provisions, etc.

Pictures and diagrams

The enhanced MAX cartography can show aerial images, land-

marks, Nav-Aids, etc and e.g. bridge diagrams. The C-card has a

collection of pictures and diagrams from key market areas. To recog-

nice when there is a picture or diagram available on the location, see

example below:

Press the cursor key to activate the chart cursor, and place the

cursor on e.g. a Port/Marina symbol

- a pop-up window will show the name of the location and list some

of the facilities. The information will stay on the screen for approx.

10 seconds. Before it disappears:

ENT

Press [ENT] to call up the info-window on the location

Use the cursor to move up/down in the list of facilities in the left

column

- details on the facilities will appear in the right column. In case

some of the details are blocked or overflows the window, use the

+/- keys to move up/down in the text lines. When there is a picture

or diagram available on the location, there will be a small image of a

camera at the top right corner. To view the picture/diagram:

PLOT

Press [PLOT] to open the picture/diagram

Press [MENU] to remove it from the screen again

CX34/44/54 Operator manual
