Reference manual
95
857-160970 / Rev.H
History
The History dialogue box is accessed from the View menu.
It displays echogram views previously saved during normal
echo sounder operation. This function greatly reduces the need
for echogram printout on paper. The presentation is made in a
separate window, and the echo sounder operates normally in the
background.
Note that the number of history files is limited to 400 in the
same directory.
Echograms covering the past hours can be viewed by operating
the scroll bar at the bottom of the dialogue; the oldest echogram
view to the left, the newest echogram view to the right.
Click the button in the lower right corner if you wish to print the
current view. If you wish to print a series of echograms click the
button with the + sign.
The echograms stored in the history files are available on
*.BMP format on the harddisk. A directory for these were
created during the installation: c:\ES60\history.
Recording, browsing and printing the history information is
described in the Operational procedures chapter. More detailed
information about the History window is provided in the
Display views chapter.
Related topics
→ Operation, page 102
→ History recording, page 48
