Display views
13
857-160970 / Rev.H
Display organisation
Main view
The ES60 display is organised as follows (from top):
• Menu bar
• For each transceiver channel:
- Two echo frames
• Status bar
A single channel display is shown below as an example.
(CD10202)
AB
C
DEF
(A) Main menu (B) Header view
(C) Echogram and range view (D) Scope view
(E) Single echo view (F) Status bar
