Operational procedures
51
857-160970 / Rev.H
Software installation and upgrades
Overview
The echo sounder is initially delivered with all necessary
software installed and configured. Software upgrades are useful
if your echo sounder fails, and you suspect a software error. An
upgrade is also required whenever the echo sounder software is
modified.
The computer should automatically detect the insertion of the
CD-ROM and open the Installation program dialogue box. If
this is not the case, you must manually run the Setup.exe
program on the CD-ROM’s root directory.
When the echo sounder software is upgraded, the software will
automatically detect the presence of General Purpose
Transceiver(s), but you will need to check that the correct
transducer(s) are enabled.
Whenever new echo sounder software is installed, you will need
to define all serial lines, transducer(s) and transceiver(s).
Related topics
→ Transceiver installation procedure, page 44.
Software installation procedure
Use this procedure if you need to install the software on a new
computer. Note that minimum hardware and software
requirements must be met by the computer.
1 Connect a keyboard to the echo sounder., or start the
On-screen keyboard application (normally located under
Accessories and Accessibility).
2 Switch on the echo sounder.
3 Insert the software CD.
4 Observe the Installation program dialogue box open.
5 If your Processor Unit is equipped with a built-in PCT
transceiver, you must enter the correct values for I/O,
DMA and IRQ. These values are given on the CD cover.
6 Press Complete installation.
7 Allow the echo sounder installation to run. Follow the
instructions provided.
8 When requested, enter the license number.
- This number is located on the CD cover. This number
is unique for each individual echo sounder.
