Simrad ES60
38
857-160970 / Rev.H
Power on/off
Use the following procedures to switch the ES60 echo sounder
on and off.
Power on
It is assumed that the echo sounder’s hardware and software are
properly installed and configured.
1 Switch power on.
- The location of the power switches are individually
assigned. The computer has its own power switch. The
transceiver(s) must be connected to separate power
supplies, and should have a remote power switch.
2 Observe the hardware test messages and operating system
start-up messages.
- It takes a couple of minutes before the echo sounder
window appears on the display.
The echo sounder memorises all its settings when power is
switched off.
If pinging does not start you must check the settings in the
following dialogue boxes:
• Operation
• Layout
• Transceiver Settings
• Transceiver Installation
If you are not successful you should use this procedure:
1 Check the Transceiver Installation dialogue box.
2 All frequency channels must be properly installed.
3 Select Factory settings in the
Options menu.
Power off
To switch off the ES60 echo sounder, observe the following
procedure.
1 Select Shutdown on the File menu.
2 Allow the computer to close all the echo sounder software
applications.
- The computer power is switched off.
3 Switch off power.
4 Switch off the power on the General Purpose Transceiver
and other peripherals (if any).
