Simrad ES60
24
857-160970 / Rev.H
Figure 6 History and printer presentation
1
9
2
3
5
7
8
6
4
(CD10210)
(4) One Event annotation with both navigational and time
information added. This annotation is controlled by the
parameters in the
Annotation dialogue box. It will only appear
on the printer output and in the History when you press the
Event number in the Status bar.
(5) One annotation with navigational information. This is
identical to item 3.
(6) One Te x t annotation with the text “Test in Horten”. This text
is entered in the Annotation dialogue box. You will need a
keyboard connected to your echo sounder to do this.
(7) Two annotations with navigational information. This is
identical to item 3.
