Simrad GC80/GC85 Expanded Gyro Compass
30 20221529 / C
4.8 Replacing the Fuses
WARNING Before a fuse is replaced, ensure that both
the main power and the emergency power is
disconnected from the unit.
Use the procedures described in the following pages when
replacing the fuses.
Master Compass
Fuse F1 is located inside the fuse holder in the front of the
Master compass.
1 Open the fuse holder by pressing and turning the fuse
holder edge counter-clockwise with a screw driver.
2 Replace fuse F1, and close the holder by turning it
clockwise.
F1 (12A)
To Next Page
