Simrad GC80/GC85 Expanded Gyro Compass
38 20221529 / C
Note! The foam rubber should be kept for re-use if the Master compass
has to be sent to factory for service!
5.3 Cabling
Note! No cables are included when the gyro system is delivered from
factory.
The wiring diagram on page 74 onwards includes cable
specification for all cables that is to be used.
Connect power and signal cables according to the wiring
diagram on page 74 onwards.
To avoid that vibration should cause the cables to loose
connection, the cables could be fastened to the fixing device by
using wire straps as illustrated on the figure.
