Simrad GC80 EXPANDED User Manual

TECHNICAL SPECIFICATION
20221529 / C 65
7.3 Input specification
Serial input signal (GPS)
Circuits:.....................................................................1
Electrical: .............. RS422/MNEA0183/Current loop
Baud rate:..................................................... 4800 bps
Data bits: ............................................................8 bits
Parity:.................................................................None
Stop bits: ...................................................................1
Transmit freq.: ...............................................1 – 5Hz
Input format:
$--GGA,x,xxxx.xx,N,xx.x,E,x,~*hh<CR><LF>
$--GLL,xxxx.xx
,N,xxxx.xx,E,*hh<CR><LF>
$--VTG,xx
,T,xx,M,xx.x,N,xx,K*hh<CR><LF>
Serial input signal (External heading)
Circuits:.....................................................................1
Electrical: ....................................RS422/NMEA0183
Baud rate:..........................................4800/38400 bps
Data bits: ............................................................8 bits
Parity:.................................................................None
Stop bits: ...................................................................1
Transmit freq.: ............................1 - 50Hz/20 – 50Hz
Input format:
$--HDT,xxx.x*hh<CR><LF>
$--HDG,xxx.x
*hh<CR><LF>
Serial input signal (LOG)
Circuits:.....................................................................1
Electrical: ....................................RS422/NMEA0183
Baud rate:..................................................... 4800 bps
Data bits: ............................................................8 bits
Parity:.................................................................None
Stop bits: ...................................................................1
Transmit freq.: ..............................................1 - 50Hz
Input format:
$--VBW,x.x,x.x,A,~*hh<CR><LF>
PULSE signal (LOG)
Circuits:.....................................................................1
Electrical: .................... 200/400 p.p.n.m., dry contact
