Simrad GC80 EXPANDED User Manual

MAINTENANCE
20221529 / C 31
Expanded Control unit
FUSE NO CAPACITY TB-NO SIGNAL DESCRIPTION
F1 TB2-5 1R24+ Power supply for ch.1 serial repeater
F2 TB2-10 2R24+ Power supply for ch.2 serial repeater
F3 TB2-15 3R24+ Power supply for ch.3 serial repeater
F4 TB2-20 4R24+ Power supply for ch.4 serial repeater
F5 TB2-29 5R24+ Power supply for ch.5 serial repeater
F6 TB2-34 6R24+ Power supply for ch.6 serial repeater
F7 TB2-39 7R24+ Power supply for ch.7 serial repeater
F8 TB2-44 8R24+ Power supply for ch.8 serial repeater
F9 TB1-31 9R24+ Power supply for ch.9 serial repeater
F10 TB1-36 10R24+ Power supply for ch.10 serial repeater
F11 TB2-61 Power supply for ch.1 step motor repeater
F12 TB2-66 Power supply for ch.2 step motor repeater
F13 TB2-71 Power supply for ch.3 step motor repeater
F14
1A
TB2-24 Power supply for ch.4 step motor repeater
F15 15A J9, 1-6 Repeater power supply
F16 J4, 23-27 Power supply for SCC and SIFC boards
F17
3.15A
J9, 15-16 Power supply for HDM part
F101 6.3A TB101 Main power supply
F102 20A TB101 Emergency power supply
