7.4 Output specification
Serial output signal 1
Circuits:...................................................................10
Electrical: ..................................................RS422/485
Baud rate:
GC80: ...................................................... 4800 bps
GC85 ..................................................... 38400 bps
Note! Baud Rate for GC85, refer Jumper settings on SIFC board,
output serial signal selection, page 95.
Data bits: ............................................................8 bits
Parity:.................................................................None
Stop bits: ...................................................................1
Transmit freq.:
GC80 .............................................................10Hz
GC85: ............................................................50Hz
Output format:
Data no.1
$ HEHDT,xxx.x,T*hh<CR><LF>
Data no.2
$ HEROT,-xxx.xx,A*hh<CR><LF>
Data no.3
$ PCICM,HEALM,xxxx,x,xx*hh<CR><LF>
Serial output signal 2 *1
Circuits:...................................................................10
Electrical: ..................................................RS422/485
Baud rate:
GC80: ...................................................... 4800 bps
GC85 ..................................................... 38400 bps
Data bits: ............................................................8 bits
Parity:.................................................................None
Stop bits: ...................................................................1
Transmit freq.:
GC80 .............................................................10Hz
GC85: ............................................................50Hz
Output format:
Data no.1
$ HEHDT,xxx.x,T*hh<CR><LF>
Data no.2
$ PTICM,--xxxx,x,xx,*hh<CR><LF>
When Gyro
is selected
When
External
heading
sensor is
selected
