Simrad GC80 EXPANDED - 11.1 Expanded Control Unit Board Settings

Simrad GC80/GC85 Expanded Gyro Compass
88 20221529 / C
11.1 Expanded control unit
Three different boards in the Expanded control unit have
jumpers and/or dip switches that may be used for configuring
the GC80/85 system.
Only a few of these jumpers/dip switches are used in installation
and pre-running procedure for the gyro compass. Refer Power
supply, page 39, and Dip-switch settings, page 40.
The following pages includes drawings showing location of
jumpers and/or dip switches, together with a short description
for the different settings.
SCC
BOARD
GTERM
BOARD
SIFC
BOARD
GPOWER
BOARD
