Speci cations | NSO evo2 Installation Manual
Speci cations
Mechanical/Environmental
Casing ABS plastic
Operating temp -15°C to +55°C
Water ingress IPx2
Weight - processor unit only 1060 grams
Dimensions (overall) 281 mm (W) x 232 mm (H) x 65.5 mm (D)
Electrical
Operating voltage 9 - 31.2 V DC
Power consumption 45 W max, 1 W off (power connected to +ve supply)
Low power standby mode yes
Protection reverse polarity and temporary over-voltage to 36V
Alarm output current 1 A
Processors iMX61 quad core (x2)
RAM DDR3 1GB
Storage 4 - 8GB Flash
Conformity CE, C-Tick, HDMI
Interfaces
Ethernet 3 ports total - 1 & 2 are PoE (RJ45 socket)
NMEA 2000 (compliant) 1 port on rear (Micro-C male, LEN = 1)
Video input 2 ports on rear (BNC female. NTCS or PAL format)
Video output (60Hz nominal) 800x600 (SVGA 4:3)
1024x768 (XGA 4:3)
1280x720 (HD 16:9)
1366x768 (WXGA)
1920x1080 (Full HD 16:9)
1920x1200 (WUXGA 16:10)
1280x800 (16:10)
1280x1024 (SXGA 5:4)
USB mass storage (Type A socket)
SD 32GB (Full size SD card socket)
NMEA 0183 port baud rate 4800, 9600, 19200, & 38400 (via proprietary cable)
RS422 port baud rate 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
Charting support Embedded low detail backround +
Insight, Navionics and CMap on SD card
7

Simrad NSO evo2 Specifications
