Importing GRIB data

GRIB data imported into memory can be displayed as chart overlay. The file can be imported

from any location that can be seen in the storage manager.

Note: GRIB data that is imported overwrites the GRIB data in memory.

You can import the GRIB files:

• From the storage manager

• From the forecast menu option on the chart panel. The Grib weather option is only

available if Grib weather is set as the overlay on the chart.

Displaying GRIB weather as overlay

Imported GRIB weather data can be displayed as an overlay on your chart panel.

When the GRIB weather overlay option is selected, the chart menu increases to show GRIB

weather options. From this menu you can select which weather symbols you want to display,

set the distance between the barbs, and adjust the opaqueness of the weather symbols.

A Wind barbs

B Pressure contours

C GRIB information window

126

Weather| NSS evo3S Operator Manual
