The shadow cursor on a multiple panel page

When using the cursor on a sonar (sonar, DownScan, or SideScan) image on a multiple panel

page, the cursor is shadowed on the other sonar (sonar, DownScan, and SideScan), chart and

radar panels.

Customizing favorite pages

Adding new favorite pages

Note: The unit display size determines the number of favorite pages allowed and the

number of application panels that can be included on a favorite page.

Edit favorite pages

Select the edit button in the favorite panel and then:

• Select the X icon on a favorite button to remove the page

• Select the tool icon on a favorite button to display the page editor dialog

Customizing the instrument bar

Note: You must activate the instrument bar in the application to access the instrument

bar menu.

Turning the instrument bar ON or OFF

By default, the Instrument bar is shown on the panel.

You can turn the instrument bar ON/OFF from the System Controls dialog.

Select a predefined instrument bar

Use the menu to select a predefined activity based instrument bar.

Changing data

You can change data from the menu.

Customizing your system | NSS evo3S Operator Manual
