Page #14 background imageLoading...
Page #14 background image
Page 1-4 Robertson AP45 Autopilot
General Information
Simrad Robertson AS
Egersund - Norway
RI9 Rudder Angle Indicator
RI9 is an analogue indicator showing the rudder position at angles up to 45
degrees on each side of midship position. The scaling is 2 degrees pr. division.
The scale illumination is adjustable by a knob on the front.
The housing is constructed of painted aluminium intended for either bulkhead or
console mounting. The splash proof construction is suitable for exposed mounting
locations.
RI35 Rudder Angle Indicator
RI35 is an analogue indicator showing the rudder position at angles up to 45
degrees on each side of midship position. The scaling is five degrees pr. division.
A front panel key is used for rudder zero adjustment and illumination adjustment.
The splash proof construction allows panel, bulkhead or bracket mounting in
exposed locations, such as bridge wings as well as wheel house and engine room.
RI35 is delivered with a 20 meter (65 feet) cable.
Rudder Angle
Indicators
