Robertson AP45 Autopilot
Installation
Simrad Robertson AS
Egersund - Norway
Page 5-19
On the inside of the feedback unit cover, a piece of moisture protecting sponge is
attached. The sponge produces a corrosion preventive gas, and to increase the
efficiency of the gas the cover must be kept tight.
Fig. 5-21
RF14XU/J45S - Wiring
The junction unit is made for bulkhead mounting and secured by screws. To
minimise length of power cables (thus avoiding voltage drop), it should be
centrally located between mains panel and power unit.
J45S Junction Unit
