Simrad ROBERTSON AP45 User Manual

Robertson AP45 Autopilot
Technical specifications
Simrad Robertson AS
Egersund - Norway
Page 4-9
Dimensions:..............................See Fig. 4-11.
Weight: ....................................1.4 kg (inclusive cable)
Max. inductive load:.................4A/24V DC, 60mA/110V AC, 25mA/220V AC
Temperature range: .................Storage: –30 to 80° C
Operation: –10 to 55° C.
Environmental protection:.......IP56
Safe distance to compass: ........0.5 m (1,6 ft.)
Power consumption (light):......6 mA
Cable: ........................................10 m cable with six wires connected through
bottom gland
Note! Cable gland can be moved to the back side.
Fig. 4-11
S35 Steering Lever - Dimensions
S35 Steering Lever
