Simrad S3009 User Manual

Dimensions - TGM60-50-xxL and TGM50-200-xxL transducers
ø69.5 mm
(2.74”)
ø88.5 mm
(3.48”)
40 mm
(1.58”)
R 8 mm
(0.31”)
R 4 mm
(0.16”)
20 mm
(0.79”)
60 mm
(2.36”)
60 mm
(2.36”)
20 m
(65.62’)
55 mm
(2.17”)
5 mm (0.2”)
ø22 mm (0.87”)
ø25 mm (0.98”)
3 mm (0.12”)
15 mm
(0.59”)
50
Appendix | S3009 Echo Sounder User Manual
