Technical specifications
Ú
Note: The most up-to-date specifications list is available at: www.navico.com/
commercial
Technical specification - S3009 Control unit
Connectivity
Sonar 1 (1 kW RMS)
NMEA 2000 1 (NMEA 2000/IEC 61162-3)
NMEA 0183 2 (NMEA 0183/IEC 61162-1)
Ethernet 1
NMEA 0183 Sentences supported See"NMEA 0183 sentences" on page 51
NMEA 2000 PGNs See "NMEA 2000 compliant PGN List" on page 52
Display
Type 9-inch diagonal, 480 x 800 pixel LCD
Backlighting LED backlit, day/night brightness with 10
increments
Screen brightness
≥ 1200 cd/m
2
Viewing angles 160° horizontal, 110° vertical
Electrical
Supply voltage 10.8 - 31.2 V DC
Power consumption - Max 12 W
Power consumption - Typical 11 W
Recommended fuse rating 3 A
Environmental
Operating temperature range -15°C (5°F) to +55°C (131°F)
Storage temperature -25°C (-13°F) to +70°C (158°F)
Waterproof rating IPx7
Humidity Up to 95% at + 40°C (104°F)
Shock and vibration According to IEC60945 ed 4.0 and RMS rules
(2-020202-040-E Vol 2 Environmental Test of
Equipment)
Physical
Dimensions See "Dimensions - S3009 Control unit" on page 49
Weight 1.95 kg (4.3 lbs)
Compass Safe Distance 0.4 m (1.31 feet)
Mounting type Panel or bracket mount
Card reader 1 (SD card)
54
Appendix | S3009 Echo Sounder User Manual
