Simrad S3009 User Manual

Dimensional drawings
Dimensions - S3009 Control unit
247 mm (9.72”)
224 mm (8.81”)
219 mm (8.62”)
80 mm
(3.14”)
67 mm
(2.63”)
100 mm (3.93”)
280 mm (11.02”) 260 mm (10.23”)
Appendix | S3009 Echo Sounder User Manual
49
