8 Repeat from step 2 until the filaments are free of contaminants as shown below.
If cleaned filament comes out with no contaminants as shown in the figure on the left below, the nozzle cleaning
is complete.
Cleaned Filament Contaminated Filament
USING NOZZLE CLEAN TOOL
If the filament does not come out of the nozzle well in step 5, proceed as follows.
Once you have completed the steps below, proceed to step 5 again.
A. Using Nozzle Cleaner
1 When the UI shown below is displayed, insert the nozzle cleaner into the nozzle tube.
To Next Page
