© Jan 2022 2-2 0607SE Maintenance Manual
SPECIFICATIONS
MEASURE
0607SE (METRIC) 1932SE (IMPERIAL)
Max. allowable inclination (front-to-
back/left-to-right)
3°/1.5°
Turning radius (inside)
0.45m 17.7in
Turning radius (outside)
1.6m 5ft 3in
Max. allowable side force (indoor/
outdoor)
400N/200N 90lbf/45lbf
Max. operating noise 72dB
POWER
Drive×steer 2 WD×2 WS
Power unit motor (voltage/power) 24V DC, 2.2 kW
Hydraulic tank capacity 4L 0.9gal (UK)/1.05gal (US)
Hydraulic system pressure 19MPa 2756psi
Battery specification (voltage,
capacity, rate of discharge)
24 V, 115 Ah, 20 hr
Power system voltage
24VDC
Control system voltage 24VDC
Charger (input voltage/output
current)
100～240 V AC/15 A
Drive motor (voltage/power)
24 V DC/0.4 kW
GROUND BEARING DATA
Max. wheel load
555kg
1224lb
Pressure against ground 1000kPa 145psi
ENVIRONMENT
Max. allowable wind speed (indoor/
outdoor)
0m/s/12.5m/s
0mph/28mph
Max. allowable altitude 1000m 3280ft
Allowable ambient temperature
(lead-acid batteries)
-10℃～40℃ 14℉～104℉
Allowable ambient temperature (-
lithium batteries)
-20℃～40℃ -4℉～104℉
Max. allowable RH
90%
Storage condition
Stored at -20℃ to 50℃ (-4℉ to 122℉) in a well-ventilated environment with
90% relative humidity (20℃ [68℉]), and away from rain, sun, corrosive gas
and inflammables and explosives.
WEIGHT
