SPECIFICATIONS
0607SE Maintenance Manual 2-3 © Jan 2022
MEASURE
0607SE (METRIC) 1932SE (IMPERIAL)
Gross weight (unladen) 1210kg
2668lb
NOTE:
a) The platform height plus the operator height (taken as 2m/6ft 7in) is the working height.
b) In different areas, hydraulic oil, engine oil, coolant, fuel and lubrication should be added in accordance with the
environmental temperature.
c) In cold weather, auxiliary devices are needed to start the machines.
d) The ground bearing data is approximate, not considering different options and only applicable when it is safe
enough.
e) The loads of persons, accessories, tools and materials are factored into the rated platform capacity.
f) The total vibration value of the platform does not exceed 2.5m/s², and the maximum root-mean-square value of
the weighted acceleration of the entire machine does not exceed 0.5m/s².
g) The hydraulic tank capacity is the maximum volume in the hydraulic tank.
MAJOR COMPONENT
WEIGHTS
UNSAFE OPERATION HAZARD
• Do not move heavy
components without
machanical assistance.
• Do not place heavy component
upon instable surface.
Table 2-2
Component Metric (kg) Imperial (lb)
Chassis assembly
757 1669
Geared reducing motor
16 35
Steer cylinder
4 9
Wheel carrier 11 24
Tire 18 40
Left door 28 62
Right door
20 44
Battery
30 66
Power unit 13 29
Scissor Assembly
327 721
Upper lift cylinder
15 33
Lower lift cylinder
29 64
