Sinoboom 0607SE - POWER SYSTEM SPECIFICATIONS

© Jan 2022 2-4 0607SE Maintenance Manual
SPECIFICATIONS
Component Metric (kg) Imperial (lb)
Platform 166 366
Note: The component weight may vary with different configurations selected.
POWER SYSTEM
SPECIFICATIONS
Table 2-3
MEASURE SPEC.
HYDRAULIC OIL
Normal temperature region (32°F ~ 104°F [0°C ~ 40°C])
L-HM46
Cold region (-13°F ~ 77°F [-25°C ~ 25°C])
L-HV32
Hot region (>104°F [40°C])
L-HM68
Extremely cold region (<-22°F [-30°C]) Special scheme to be determined
HYDRAULIC PUMP
Type Gear pump
Displacement
2.1cc/r
Max drive pressure 25MPa (3625Psi)
DRIVE MOTOR
Voltage
24V
Rated rpm 4300rpm
Power 400W
FUCTION VALVE
Lift relief valve pressure 19MPa (2755Psi)
RETURN FILTER
Return filter bypass pressure 0.09MPa (13Psi)
NOTICE
Different hydraulic oils can be added according to
customer requirements upon factory delivery, but
cannot be mixed.
