© Jan 2022 5-16 0607SE Maintenance Manual
MAINTENANCE
machine should drive at 0.8km/h (0.5mph), or 123
～150s for a distance of 30m (98ft 5in).
—DTC system: Press the drive/steer function
enable button on the platform controller, hold
the enable switch on the control handle and
slowly deflect forwards to full drive speed. The
machine should drive at 0.8km/h (0.5mph), or
123～150s for a distance of 30m (98ft 5in).
NOTICE
If the machine takes less than 123s to travel 30m
(98ft 5in), tag and remove the machine from
service.
Turtle speed test:
6. —SINOBOOM system: After turning the lift function
enable switch on the platform controller upwards,
the indicator light should come on. Hold the enable
switch on the control handle and deflect backwards
to activate the lower function. Lower the machine to
the non-operating position.
—DTC system: Press the lift function enable
switch on the platform controller, hold the
enable switch on the control handle and deflect
backwards to activate the lower function.
Lower the machine to the non-operating
position.
7. —SINOBOOM system: After turning the drive/steer
function enable switch on the platform controller
downwards, the indicator light should come on.
Then turn the high/low drive speed select switch
upwards, and the low drive speed mode shall be
active.
—DTC system: After pressing the drive/steer
function enable button on the platform
controller, and pressing the high/low drive
speed select button, the low drive speed button
light shall come on.
8. Hold the enable switch on the control handle and
slowly deflect forwards to full drive speed. The
machine shoud drive at 2km/h (1.24mph), or 50～
59s for a distance of 30m (98ft 5in).
NOTICE
If the machine takes less than 50s to travel 30m
(98ft 5in), tag and remove the machine from
service.
High speed test:
9. —SINOBOOM system: Turn the high/low drive
speed select switch downwards again , and the
high drive speed mode shall be active.
—DTC system: Turn the high/low drive speed
select switch downwards again, and the low
drive speed button light should be off.
10. Hold the enable switch on the control handle and
slowly deflect forwards to full drive speed. The
machine shoud drive at 4km/h (2.5mph), or 25～
30s for a distance of 30m (98ft 5in).
NOTICE
If the machine takes less than 25s to travel 30m
(98ft 5in), tag and remove the machine from
service.
B-11 Inspect Tilt Protection
UNSAFE OPERATION HAZARDS
• Do not place your hands and arms
where they may become crushed
or trapped.
• Do not work in or under the
platform or near the scissor arms
when the safety arm is not in
place.
NOTICE
Perform this step while you are standing on the
ground using the platform controller. Do not stand on
the platform while testing this function.
EMERGENCY
S
T
O
P
4
5
6
7
1
2
3
8
EMERGENCY
S
T
O
P
10
11
12
9
