REPAIR
Code Problem Action Limit Solution
Ft
Foot pedal no action
Disable PCU Control
Foot pedal no action: when operate the joystick to
drive and lift, there is no action on foot pedal, so
please check the switch of foot pedal.
CL
Anti-collision switch
warning
Disable Lifting and Driving
Anti-collision switch warning: When lifting up and
close to the obstacle, warning and check the anti-
collision switch.
Fundamental Troubleshooting
Table 6-8
Problem Cause Solution
Machine power off
The equipment has not been
powered on
• The key switch is in the OFF position.
• The platform controller or the ground controller
emergency stop button is in the OFF position.
• The platform controller is malfunctioning or not
powered off after downloading of a program.
• The ground controller is malfunctioning or not
powered off after downloading of a program.
Machine
communication fault
CAN equipment is offline
• Inspect whether the leads of the power supply and
communication are inserted properly and reliably.
• Inspect whether all pins of the Deutsch plugs for the
platform controller and ground controller connecting
cables are wired according to the drawing.
• Inspect whether the platform controller plug or the
plug of the connecting cable between the platform
controller and ground controller are in good contact.
• Inspect whether the platform controller is
malfunctioning.
• Inspect whether the Deltatech plug of ground
controller is firm or correct.
Operation of the
ground controller is
invalid
The key switch has not been
turned to the operation of the
ground control position
• The key switch is not placed on the ground control
position.
• The system has not been powered off after the
program is downloaded to the platform controller.
Operation of the
platform controller is
invalid
The key switch has not been
turned to the operation of the
platform control position
• The key switch is not placed on the ground control
position.
• The system has not been powered off after the
program is downloaded to the platform controller.
• Inspect whether the platform controller is
malfunctioning.
Level status tilting is
always sounding alarm
The level switch has not been
connected or has trouble
• Inspect whether the level switch is inserted properly
and firmly.
• Inspect whether the level switch is malfunctioning.
