REPAIR
0607SE Maintenance Manual 6-35 © Jan 2022
Code Problem Action Limit Solution
80
Over 80% Load
Warning
Warning Only
Over 80% Load Warning: Platform is getting close
to its limit of weight. Consider not adding more
load.
81
Right Drive Motor
Short Fault
Disable All Motion
Right Drive Motor Short Fault: Check the Motor
connections and make sure they are tight. Check
the Motor for a short.
82 Left Brake Coil Fault
Disable Lifting and Driving
Left Brake Coil Fault: Check the connections to the
Coil’s terminals and make sure they are tight. If so,
check the coil itself to see if it is open or shorted.
83
Right Brake Coil Fault Disable Lifting and Driving
Right Brake Coil Fault: Check the connections to
the Coil’s terminals and make sure they are tight. If
so, check the coil itself to see if it is open or
shorted.
84 Motor Post Shorted
Disable Lifting and Driving
Motor Post shorted: Check the connections of the
controller and motor. Make sure the wiring is not
shorted.
85
Brake Release Switch
On
Diagnostic Message Only
Brake Release Switch On: Check the wires to
brake release switch or look for a stuck switch.
86
Brake Release Switch
On
Diagnostic Message Only
Brake Release Not Stowed: Check if the platform
is below down limit height. Check the down limit
switch and connections.
87
Brake Release Not
Showed
Diagnostic Message Only
Brake Release Need Switch On: Check the wires
to brake release switch or look for a stuck switch.
Check the wires to the Toggle Switch or look for a
stuck Toggle Switch.
89
Motor Field Open Disable Lifting and Driving
Motor Field Open: The field voltage is different
from 1/2 Vbatt. Check connections of the field
wires or leakage to the vehicle frame.
90
Over 90% Load
Warning
Warning Only
Over 90% Load Warning: Platform is getting close
to its limit of weight. Consider not adding more
load.
91 Left Motor Field Short
Disable Lifting and Driving
Left Motor Field Short: Check connections of the
field wires or leakage to the vehicle frame.
92
Right Motor Field
Short
Disable Lifting and Driving
Right Motor Field Short: Check connections of the
field wires or leakage to the vehicle frame.
99
Over 99% Load
Warning
Warning Only
Over 99% Load Warning: Platform has reached its
limit of weight. Do not add more load.
OL
Overloaded Platform
Fault
Disable All Motion
Overloaded Platform Fault: Remove the excess
load immediately.
OH
PlatformHighestPosit-
ion Warning
Disable Lifting
Platform Highest Position Warning: Lower the
machine.
LL Machine Tilted
Disable Lifting and Driving
Machine Tilted Beyond Safe Limits Fault: If the
machine is tilted, find a way to make it level. If the
machine is level, check the wiring to the tilt sensor
and then the sensor itself.
