MAINTENANCE
Figure 5-12
4. After the hydraulic oil is fully drained, remove the
hydraulic tank retaining screws and clamps to
remove the hydraulic tank from the power unit
assembly.
Figure 5-13
5. Rinse out the inside of the tank using a mild solvent,
and dry it up.
6. Mount the hydraulic tank to the power unit
assembly.
7. Mount the power unit assembly to the inside of right
chassis door. For specific steps, please see
Hydraulic Power Unit, page 6-7.
8. Add new hydraulic oil.
