REPAIR
0607SE Maintenance Manual 6-27 © Jan 2022
Cod-
e
Problem Action Limit Solution
the bound relationship or replace the GPS
module.
10
Indoor Models Switch Outdoor
Mode Fault
Alarm only
Switch outdoor model to indoor model
12
ECU Key Fault
Disable Chassis
Control
Toggle Switch Up or Down Fault: Make sure
nothing is pressing the chassis toggle switch or
ECU button, check the wiring of the chassis
toggle switch. If that does not resolve the
problem, try replacing the ECU.
18 Pothole Guard Fault
Disable Lifting
and Driving
Pothole Guard Fault: Check that the pothole
guards are not extended, check the pothole limit
switches. Check wires to the switches, check the
down limit switch and connections.
20 BMS Comm. Fault
Disable Lifting
and Driving
BMS Comm. Fault: Check communications cable
connections and other wiring.
21
Discharge Temperature Fault 1 Alarm only
Discharge Temperature Fault 1: Inform BMS
factory to check battery.
22
Discharge Current High Fault 1 Alarm only
Discharge Current High Fault 1: Inform BMS
factory to check battery.
23
Total Voltage Low Fault 1
Disable Lifting,
and Driving at
low speed
Total Voltage Low Fault 1: Inform BMS factory to
check battery.
24
Cell Voltage Low Fault 1
Disable Lifting,
and Driving at
low speed
Cell Voltage Low Fault 1: Inform BMS factory to
check battery.
25
Cell Voltage Low Fault 2
Disable Lifting
and Driving
Cell Voltage Low Fault 2: Inform BMS factory to
check battery.
26
Sharp Difference in Voltage
Disable Lifting
and Driving
Sharp Difference in Voltage: Inform BMS factory
to check battery.
27
Sharp Difference in Temperature
Disable Lifting
and Driving
Sharp Difference in Temperature: Inform BMS
factory to check battery.
28
Discharge Current High Fault 2
Disable Lifting
and Driving
Discharge Current High Fault 2: Inform BMS
factory to check battery.
29
Discharge Temperature Fault 2
Disable Lifting
and Driving
Discharge Temperature Fault 2: Inform BMS
factory to check battery.
30 GPS Lock Ⅰ
Alarm only
Contact SINOBOOM after-sales staff.
31 Pressure Sensor 1 Fault
Disable All
Motion
Pressure Sensor 1 Fault: Check the wiring to the
sensor and then the sensor itself. Also check to
make sure that the correct option is properly
selected for load sensing.
32
Angle Sensor Fault
Disable All
Motion
Angle Sensor Fault: Check the wiring to the
sensor and then the sensor itself. Also check to
make sure that the correct option is properly
selected for angle sensing.
