5.2 Operating Controls
The welding laser system is operated using the elements described in the following.
User Interface
Illustration 5 Operating Panel
The user interface of the welding laser system is a 7-inch colour touchscreen with 800
x 480 pixels. This screen can display the real time image of the laser weld point and
various status indicators and operating parameters, etc. Via the touchscreen the
operator can switch the device on and off and set the parameters.
