IM Machine Name Rev.: END 42
Illustration 19 Filter Fleece
● Replace the contaminated filter fleece.
● Secure the filter cover together with the new filter fleece again using the four fixing
screws.
6.4 Repairs
Repair work on the welding laser system must only be carried out by the trained and
authorized specialists of the operating company. The instructions in this chapter are
limited to important general information and instructions that must be followed during
repair work.
Categorically applicable to all assembly and dismantling work:
● Label all components together with their interrelationships.
● Identify the installation position and location and record this data.
● After re-installing, re-tighten all mechanical connections.
● Check the safety devices as described in Chapter 6.2.3 Checking of
the Safety Devices.
