7. Electronic control unit Page 40
EN
7.1.3.2. Set interval time and contact time
(KFAS)
First activate programming mode ( Table21). The
interval time is displayed as the first adjustable
parameter.
Set the interval time and the contact time as
described in Table22. Observe the value ranges
in Table20 or in the Technical Data. The
PAUSE or CONTACT LEDs will flash while you make
the changes.
Table 22. Set interval time and contact time (KFAS)
Step
Button
Action
Display
Programming mode is active.
The first adjustable parameter is displayed.
Example: Interval time in timer mode
The PAUSE LED flashes.
1
Press briefly.
(select the parameter)
The current value for the interval time is
displayed.
Example: 24 h
The PAUSE LED flashes.
2
Press repeatedly until
the desired value is set.
The new value is displayed.
Example: 36 h
The PAUSE LED flashes.
3
Press briefly.
(confirm the new value)
Display the next parameter.
Example: Contact time in timer mode
The CONTACT LED flashes.
The new value for the "interval time"
parameter has been confirmed and stored
in the control unit's non-volatile memory.
Continued on next page
