Channel LEDs
The LEDs CH1 and CH2 for the lubrication channels are only used in dual-channel systems.
LED Description
CH1
The red LED lights up when channel 1 is in alarm mode.
The green LED lights up when channel 1 is in normal mode.
The LED blinks when channel 1 is selected on the display.
CH2
The red LED lights up when channel 2 is in alarm mode.
The green LED lights up when channel 2 is in normal mode.
The LED blinks when channel 2 is selected on the display.
Function LEDs
The LEDs indicate the operation of the channel which is selected on the display.
LED Description
L1
The green LED lights up when main line 1 is being pressurised.
The green LED is on during the interval when main line 1 was pressurised last.
The red LED blinks when main line 1 is in pressure alarm mode.
L2
The green LED lights up when main line 2 is being pressurised.
The green LED is on during the interval when main line 2 was pressurised last.
The red LED blinks when main line 2 is in pressure alarm mode.
P
The green LED lights up when the pressurisation phase is in progress.
The red LED blinks when the pumping centre is in low level alarm mode.
