3. General description
Maxilube pumping centre
The pumping centre of the SKF MaxiLube central lubrication system is designed for pumping lubricant into a centralised
lubrication system. The pumping centre can be controlled and monitored using a control unit integrated in the changeover
valve unit, by sending SMS messages or by means of external control.
The Maxilube pumping centre consists of a pump (I), a lid set (II), a pressure air regulator (III) and a changeover valve unit
(IV) with accessories.
Fig. 2 Design of the SKF Maxilube pumping centre
Position Description
I
Pump
II
Lid set (ECO or STA)
III
Pressure air regulator
IV
Changeover valve unit
